Examples of U-MaxiGrip Zipper Applications: E-case, Dry Bag, Medical Bag

U-MAXIGRIP | UMX Series

Closeup of U-MaxiGrip Re-sealable Closure

Chemical Resistant, Waterproof, Silent Plastic Zippers for Sealing Two Parallel Planes Together

The U-MaxiGrip heavy-duty zip lock closure system is an ideal solution for top or vertical seal applications where two parallel planes come together. Our waterproof zipper components are available in a variety of sizes and strengths to fulfill all of your barrier closure protection needs, from simple weatherproofing of outdoor equipment to containment of biohazard and medical waste.

UMX 20

Profile Illustration of UMX20 2-Track Zipper

Product Sheet





Tracks
  • 2 Track
Strength
  • Light Duty
  • 5 - 10 lbs. Pull Strength*
Closures

Illustration of Zipper Closing Manually by Hand

Manually By Hand

Illustration of Ultraseal Parking Slider Closure

Ultraseal Parking Slider

Colors
  • Black
  • White
  • Clear
  • Custom Per Request

* Pull strength varies with materials, durometer, and fullness of track teeth. We ask for your requirements to determine feasibility. Figures based on testing done on an Instron model 3343 based on 1 inch sample at 20 inches of travel per minute with a 100 pound load cell.

Drawing of Dimensional Specs of UMX20 2-Track Zipper

This sketch is for reference only. Dimensions vary according to raw material.

UMX 28

Profile Illustration of UMX28 2-Track Zipper

Product Sheet





Tracks
  • 2 Track
Strength
  • Medium Duty
  • 10 - 20 lbs. Pull Strength*
Closures

Illustration of Zipper Closing Manually by Hand

Manually By Hand

Illustration of Ultraseal Parking Slider Closure

Ultraseal Parking Slider

Colors
  • Black
  • White
  • Clear
  • Custom Per Request

* Pull strength varies with materials, durometer, and fullness of track teeth. We ask for your requirements to determine feasibility. Figures based on testing done on an Instron model 3343 based on 1 inch sample at 20 inches of travel per minute with a 100 pound load cell.

Drawing of Dimensional Specs of UMX28 2-Track Zipper

This sketch is for reference only. Dimensions vary according to raw material.

UMX 39

Profile Illustration of UMX39 2-Track Zipper

Product Sheet





Tracks
  • 2 Track
Strength
  • Heavy-to-Industrial Strength Duty
  • 20 - 30 lbs. Pull Strength*
Closures

Illustration of Zipper Closing Manually by Hand

Manually By Hand

Illustration of 2 Track Roller Closure

2 Track Roller

Colors
  • Black
  • White
  • Clear
  • Custom Per Request

* Pull strength varies with materials, durometer, and fullness of track teeth. We ask for your requirements to determine feasibility. Figures based on testing done on an Instron model 3343 based on 1 inch sample at 20 inches of travel per minute with a 100 pound load cell.

Drawing of Dimensional Specs of UMX39 2-Track Zipper

This sketch is for reference only. Dimensions vary according to raw material.

UMX 39

Profile Illustration of UMX39 3-Track Zipper

Product Sheet





Tracks
  • 3 Track
Strength
  • Heavy-to-Industrial Strength Duty
  • 20 - 30 lbs. Pull Strength*
Closures

Illustration of Zipper Closing Manually by Hand

Manually By Hand

Illustration of 3 Track Roller Closure

3 Track Roller

Colors
  • Black
  • White
  • Clear
  • Custom Per Request

* Pull strength varies with materials, durometer, and fullness of track teeth. We ask for your requirements to determine feasibility. Figures based on testing done on an Instron model 3343 based on 1 inch sample at 20 inches of travel per minute with a 100 pound load cell.

Drawing of Dimensional Specs of UMX39 3-Track Zipper

This sketch is for reference only. Dimensions vary according to raw material.

Weld Compatibility

Product Material x Zipper Material


PE
PVC
PU
CPE
VYT
TPE-E
PP
TPO


PE
I
U


I



I


PVC

W
R
H

W
H
U
W
R
H
U
W
H
R




PU


W
H
W
H
W
H
U





CPE
I
W
H
U
W
H
W
H
I
W
H
U
W
H
I
I
U
W
H
I
U


VYT

W
R
H
U
W
H
U
W
H
U
W
R
H





TPE-E

W
H
R

W
H
I

W
H
I
U




PP



I
U


I
U



TPO
I


W
H
I
U



W
I


W Wedge Weld
R Radio Freq. Weld
H Hot Air Weld
I Impulse Weld
U Ultrasonic Weld


MaxiGrip provides several convenient plastic resealable zipper attachment options designed to work with your product applications. Our heavy-duty, waterproof zippers are compatible with the following methods:

  • Welding (preferred method)
  • Stitching - French Needle (double row), Lockstitch (4-5 stitches per inch)
  • Bonding - Glue, Adhesives

Contact Us for Samples or More Information

Our versatile and comprehensive closure system is sure to fit your design requirements and protection needs. We will assist you in determining the exact requirements that will work for your specific needs and intended application. Samples are available upon request.
